Lengths
2-3-4-5-8-10-12-15-18-20-25-30-35-40-45-50-55-60
For special lengths, please contact our sales dept.
Material Code
B = brass nickel plated
S = mild steel zinc plated
SS = stainless steel
How to order
Type + Inside Dia. + Outer Dia. + Length + Material Code
Example: CH-22-40-8-B or CH-32-60-12-SS
| A Inside Dia. mm |
B Outer Dia. mm |
C Length mm |
Please note! | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min. | Max. | |||||||||||||||
| 2.2 | 4.0 | 2 | 30 | Can be customized | ||||||||||||
| 2.5 | 5.0 | 2 | 30 | Can be customized | ||||||||||||
| 3.2 | 6.0 | 2 | 60 | Can be customized | ||||||||||||
| 4.3 | 8.0 | 2 | 60 | Can be customized | ||||||||||||
| 5.3 | 10.0 | 2 | 50 | Can be customized | ||||||||||||
